Yunus Sheets and Plates, based in Istanbul, Turkey, stands out as a top manufacturer and supplier of Stainless Steel 316H Sheets and Plates. They pride themselves on delivering high-quality stainless steel products that are designed for strength, durability, and exceptional performance even in high-temperature settings. Renowned for their precision manufacturing and commitment to international standards, the company offers sheets and plates that excel in resisting corrosion, pitting, and crevice attack. These Stainless Steel 316H Sheets and Plates are particularly ideal for industrial environments where high temperatures are the norm. With state-of-the-art production facilities and strict quality control measures, Yunus Sheets and Plates guarantees reliable, long-lasting products for a variety of applications in the chemical, petrochemical, marine, and industrial sectors around the globe.
Stainless Steel 316H Sheets and Plates are made from an austenitic stainless steel alloy that primarily consists of iron, chromium (16–18%), nickel (10–14%), molybdenum (2–3%), and a higher carbon content, along with trace amounts of manganese, silicon, phosphorus, and sulfur. The increased carbon content boosts strength at elevated temperatures while still providing excellent resistance to pitting and crevice corrosion. In terms of mechanical properties, these sheets and plates deliver high tensile and yield strength, good toughness, and outstanding creep resistance. They maintain their shape and durability under thermal and mechanical stress, making them perfect for demanding high-temperature and corrosive applications.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.030 max | 16 – 18 | 2 – 3 | 10 – 14 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 316H | 1.4401 | S31609 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 316H Sheet and Plates offers several key benefits, especially in high-temperature environments. Its high carbon content also increases creep resistance, making it ideal for structural application in the chemical, petrochemical and marine industries. The material boasts excellent corrosion resistance, especially against chloride, pitting and crevice corrosion. It also performs well in extreme temperatures, maintaining its integrity in high temperature conditions. In addition, stainless steel 316H is durable, easy to manufacture, and highly resistant to oxidation, providing long service life with minimal maintenance These properties make it ideal for environmental production difficult to destroy.
Industries that require high-temperature strength and corrosion resistance widely use Stainless Steel 316H Sheets and Plates. In the chemical and petrochemical fields, they find applications in process vessels, heat exchangers, and piping systems that come into contact with aggressive chemicals. In marine settings, they are utilized in seawater handling equipment, shipbuilding components, and offshore platforms. The power generation sector also relies on them for boilers, superheaters, and high-temperature structural components.
