Yunus Sheets and Plates, located in Istanbul, Turkey, stands out as a top manufacturer and supplier of Stainless Steel 310H Angle, delivering high-quality products that meet international standards. With state-of-the-art production facilities and rigorous quality control measures, Yunus guarantees reliable, durable, and precisely crafted stainless steel solutions for a variety of industries. The Stainless Steel 310H Angle is well-known for its impressive high-temperature strength, oxidation resistance, and durability in tough service conditions. By offering cost-effective solutions, timely deliveries, and a strong focus on customer service, Yunus has built a solid reputation in both local and global markets across numerous industrial applications.
Stainless Steel 310H Angle is an austenitic stainless steel alloy that contains 24–26% chromium and 19–22% nickel, along with a higher carbon content compared to 310/310S. This increased carbon level enhances creep resistance and strength at elevated temperatures. In terms of mechanical properties, it boasts a tensile strength of about 515 MPa, yield strength of 205 MPa, elongation of 40%, and a maximum Brinell hardness of 225. These well-balanced characteristics enable SS 310H Angles to excel in high-heat applications while preserving structural integrity and ensuring a long service life.
| Specifications | : | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 310H Angle | : | 5mm to 9mm |
| SS 310H Channel | : | 40mm*20mm~300mm*300mm |
| SS 310H Beam | : | 3″ thru 12.31″ |
| SS 310H Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 310H | 0.04 – 0.10 | 2 max | 1.0 max | 0.045 max | 0.030 max | 24 – 26 | – | 19 – 21 | 53.885 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310H | S31009 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yunus Sheets and Plates based in Istanbul, Turkey, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 310H angle provides excellent resistance to high temperature oxidation and corrosion, making it ideal for use in furnaces, heat exchangers and exhaust systems Its high chromium and nickel content provides excellent strength and durability exist longer at higher temperatures. The alloy has excellent weldability and formability, making it suitable for structural applications. In addition, the stainless steel 310H surface retains its mechanical properties in areas of thermal cycling and chemical exposure These properties ensure durability and reliability in applications such as petrochemical, aerospace, and in power generation.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Industries that require resistance to high temperatures and oxidation widely use Stainless Steel 310H Angles. They are often found in furnace components, heat treatment equipment, kilns, and parts for power plants. The petrochemical and chemical sectors utilize them in processing equipment that comes into contact with high-temperature gases and corrosive substances. Additionally, they are used in boiler supports, exhaust systems, and thermal processing units where long-lasting strength and durability are essential. Their versatility and outstanding performance in extreme conditions make SS 310H Angles a go-to choice for heavy-duty and high-temperature industrial applications around the globe.
