Yunus Sheets and Plates, located in Istanbul, Turkey, stands out as a top manufacturer and supplier of high-quality Titanium Grade 2 Angles. Known for their precision engineering and durable products, this company caters to a variety of industrial sectors, offering customized solutions that align with international standards. Their Titanium Grade 2 Angles are produced using advanced techniques, ensuring exceptional dimensional accuracy, a smooth surface finish, and long-lasting performance. With a strong commitment to reliability and customer satisfaction, Yunus Sheets and Plates blends technical know-how with a solid supply chain, making them a trusted partner for clients in need of premium titanium products for critical applications.
These Titanium Grade 2 Angles are primarily made from commercially pure titanium, which provides excellent corrosion resistance and biocompatibility. With a low density of about 4.51 g/cm³, they boast a high strength-to-weight ratio while maintaining impressive toughness and ductility. Their mechanical properties include a tensile strength of roughly 345 MPa, a yield strength of 275 MPa, and an elongation of 20–25%, ensuring they hold up well under stress. Their remarkable thermal stability and resistance to oxidation at high temperatures make them perfect for challenging environments, while their non-magnetic nature and outstanding fatigue resistance enhance their performance in specialized industrial applications.
Dimensions: ASME, ASTM, EN, BS, GB, DIN, JIS, etc
Size : Grade 2 Titanium angle bar sizes : 3/4″ THRU 8″
Channel Size : Base: 80 to 150 mm Side: 40 to 75 mm
Thickness: Angle Thickness: 1/8″ thru 5/8″
Channel Thickness : Base: 5 to 6 mm (depending on size)
Angle Length: Upto 6 Meters Long
Processing: Bar Cutting
Application: Paper Industry, Architucture, Construction, Kitchen Equipment, Pharma, Engineering Industries And Many More
Angle Types: Angles, Angle Bars, Equal Angle, Unequal Angle, L Shape Angles, Equal Leg Angle, Unequal Leg Angle, T Shaped Angle
Channel Types: Channel, Channel Bars, C-channel, U-Channel, Strut Channels, Miscellaneous Channel, MC Channels, Unistrut Channels
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr 2 | 3.7035 | R50400 |
| Element | C | Mn | N | H | Ti | Fe | O |
| Titanium Gr2 | 0.1 max | 2.00 max | 0.03 max | 0.015 max | 99.2 min | 0.3 max | 0.25 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness (Brinell) |
| Titanium Gr2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Titanium Grade 2 Angles find extensive use in the chemical processing, marine, aerospace, and medical industries, thanks to their exceptional corrosion resistance and strength. They are perfect for building frameworks, supports, and structural components in harsh environments where durability and longevity are essential. Additionally, they are utilized in desalination plants, heat exchangers, and offshore structures, delivering reliable performance in both high-temperature and corrosive settings. Their lightweight yet sturdy design makes them ideal for aerospace and transportation applications.
Titanium Grade 2 angle offers several key advantages, making it ideal for demanding applications. Its excellent corrosion resistance, particularly in marine and chemical environments, ensures long-lasting performance. With a high strength-to-weight ratio, Ti Gr 2 provides durability without adding excessive weight, making it perfect for aerospace and structural applications. Its superior weldability and formability allow for easy fabrication into complex shapes. Additionally, Titanium Grade 2 exhibits good fatigue resistance and can perform well in temperatures up to 400°C, offering reliability and versatility in a variety of industries.
| Sizes (all Dimensions in milimeter) | Approx Weight Titanium Gr.2 Angle Bar (kilogram/meter) | Titanium Gr 2 Angle Bar Sizes (all Dimensions in milimeter) | Approx Weight Titanium Grade 2 Angle Bar (kilogram/meter) |
|---|---|---|---|
| 25 x 25 x 3 | 1.13 | 63 x 63 x 8 | 7.50 |
| 25 x 25 x 4 | 1.46 | 65 x 65 x 4 | 4.00 |
| 25 x 25 x 5 | 1.78 | 65 x 65x 5 | 5.02 |
| 30 x 30 x 3 | 1.37 | 65 x 65 x 8 | 7.75 |
| 30 x 30 x 4 | 1.78 | 70 x 70 x 5 | 5.35 |
| 30 x 30 x 5 | 2.20 | 70 x 70 x 6 | 6.40 |
| 40 x 40 x 3 | 1.83 | 75 x 75 x 6 | 6.85 |
| 40 x 40 x 4 | 2.41 | 75 x 75 x 8 | 9.05 |
| 40 x 40 x 5 | 2.97 | 80 x 80 x 6 | 7.35 |
| 50 x 50 x 4 | 3.05 | 80 x 80 x 8 | 9.65 |
| 50 x 50 x 5 | 3.78 | 80 x 80 x 10 | 11.98 |
| 63 x 63 x 4 | 3.90 | 100 x 100 x 8 | 12.20 |
| 63 x 63 x 5 | 3.90 | 100 x 100 x 12 | 18.00 |
| Size in Inches | Est. Weight per Ft. Lbs. | Est. Weight per 20′ Bar |
|---|---|---|
| 3/4 x 3/4 x 1/8 | 0.59 | 11.80 |
| 1 x 1 x 1/8 | 0.80 | 16.00 |
| 1 x 1 x 3/16 | 1.16 | 23.20 |
| 1 x 1 x 1/4 | 1.49 | 29.80 |
| 1-1/4 x 1-1/4 x 1/8 | 1.01 | 20.20 |
| 1-1/4 x 1-1/4 x 3/16 | 1.48 | 29.60 |
| 1-1/4 x 1-1/4 x 1/4 | 1.92 | 38.40 |
| 1-1/2 x 1-1/2 x 1/8 | 1.23 | 24.60 |
| 1-1/2 x 1-1/2 x 3/16 | 1.80 | 36.00 |
| 1-1/2 x 1-1/2 x 1/4 | 2.34 | 46.80 |
| 2 x 2 x 1/8 | 1.65 | 33.00 |
| 2 x 2 x 3/16 | 2.44 | 48.80 |
| 2 x 2 x 1/4 | 3.19 | 63.80 |
| 2 x 2 x 3/8 | 4.70 | 94.00 |
| 2-1/2 x 2-1/2 x 3/16 | 3.07 | 61.40 |
| 2-1/2 x 2-1/2 x 1/4 | 4.10 | 82.00 |
| 3 x 3 x 1/4 | 4.90 | 98.00 |
| 4 x 4 x 1/4 | 6.60 | 132.00 |
| 4 x 4 x 3/8 | 9.80 | 196.00 |
Yes, we offer custom sizes for Titanium Grade 2 Angle to meet specific project needs. Our team at Yunus Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Titanium Grade 2 angle is widely used in industries requiring high strength, corrosion resistance, and lightweight materials. Common applications include aerospace components, where its strength-to-weight ratio is crucial for aircraft and spacecraft structures. It is also utilized in marine environments for shipbuilding and offshore platforms, due to its resistance to saltwater corrosion. Additionally, Ti Gr 2 angles are used in chemical processing, heat exchangers, and medical devices, offering reliability and durability in harsh conditions. Its versatility makes it ideal for a broad range of industrial and structural applications.
