**SA 515 Grade 60 Sheets and Plates** are medium-carbon, silicon-killed steels designed for pressure vessel applications, primarily used in welded boilers and pressure vessels. They boast good weldability and moderate tensile strength, typically ranging from 415 to 550 MPa. The plates undergo a normalization process to enhance toughness and ductility, making them suitable for high-temperature applications. Their composition generally includes carbon (up to 0.30%), along with controlled amounts of manganese, phosphorus, and sulfur. SA 515 Gr. 60 meets ASME and ASTM standards, ensuring consistent mechanical properties and chemical composition across various batches and thicknesses.
| Specifications | ASTM A515 Gr. 60 / ASME A515 Grade 60 | |
| Thickness |
| |
| Length | 3000 mm – 8000 mm | |
| Width | 1500-3500mm | |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) | |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR) | |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | P | S | Si |
|---|---|---|---|---|---|
| A515 Grade 60 | 0.24-0.31 | 0.98 max | 0.035 max | 0.035 max | 0.13-0.45 |
| Grade | Thickness | Yield | Tensile | Elongation |
|---|---|---|---|---|
| A515 Grade 60 | 50-200mm | MPa -220 min | MPa – 415-550 | 21-25% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
**SA 515 Grade 60 Sheets and Plates** find their place in the fabrication of pressure vessels, heat exchangers, storage tanks, and boiler components. These plates are particularly well-suited for industries like oil and gas, chemical processing, power generation, and refinery operations, where materials must withstand high pressure and moderate heat. Thanks to their excellent weldability, formability, and dimensional stability, SA 515 Grade 60 plates are also utilized in a variety of applications, ensuring reliability and performance in demanding environments.
SA 515 Grade 60 sheets and plates offer several advantages, including excellent strength, durability, and resistance to high temperatures and pressure, making them ideal for use in boilers, pressure vessels, and heat exchangers. Their outstanding weldability and formability ensure easy fabrication and installation. These materials also provide good machinability and long-term performance, even in challenging environments. With their ability to withstand thermal stress and corrosion, SA 515 Grade 60 sheets and plates are a reliable choice for industries requiring safe and efficient operation in demanding conditions.
Yes, we offer custom sizes for ASTM SA 515 grade 60 Sheets and Plates to meet specific project needs. Our team at Yunus Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
SA 515 Grade 60 sheets and plates are widely used in industries requiring high strength and resistance to elevated temperatures and pressure. Common applications include the manufacturing of boilers, pressure vessels, heat exchangers, and storage tanks. They are also used in the petrochemical, chemical, and power generation industries for critical components that must withstand thermal stress and high-pressure environments. Additionally, these materials are ideal for constructing piping systems and other structural components where strength, durability, and performance under extreme conditions are essential.
