Yunus Sheets and Plates, located in Istanbul, Turkey, stands out as a top manufacturer and supplier of high-performance metal products, including the renowned Rene 41 Foil. With a reputation built on precision engineering and rigorous quality control, they cater to a variety of industries by delivering reliable and durable materials. The company places a strong emphasis on customer satisfaction, ensuring timely deliveries and customized solutions to meet unique needs. Thanks to their extensive knowledge of advanced alloys, Yunus Sheets and Plates guarantees that every Rene 41 Foil product adheres to international standards, making it a go-to choice for applications that demand exceptional heat resistance, strength, and longevity.
Rene 41 Foil is a nickel-based superalloy, primarily made up of nickel, cobalt, chromium, molybdenum, titanium, and aluminum. It boasts impressive high-temperature strength, creep resistance, and oxidation stability. The mechanical properties of this foil include remarkable tensile strength, fatigue resistance, and dimensional stability, even when faced with extreme thermal stress. Its microstructure can be fine-tuned through heat treatment to enhance performance in challenging environments. Rene 41 Foil maintains its integrity at temperatures above 700°C, making it perfect for applications that require both high strength and resistance to thermal degradation, all while offering excellent machinability and corrosion resistance.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Yunus Sheets and Plates based in Istanbul, Turkey, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
You’ll find Rene 41 Foil widely used in the aerospace, automotive, and power generation sectors, where high-temperature performance is essential. It’s commonly found in turbine blades, jet engine components, and rocket motor parts, thanks to its outstanding creep and oxidation resistance. The foil also plays a crucial role in precision components for industrial gas turbines, high-performance heat exchangers, and structural parts that endure extreme stress. Its reliability under prolonged high temperatures ensures operational efficiency and safety. Moreover, Rene 41 Foil fosters innovation in advanced engineering applications, empowering manufacturers to push the boundaries of what’s possible.
Yes, we offer custom sizes for Rene 41 Foil to meet specific project needs. Our team at Yunus Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Rene 41 foil is widely used in aerospace, gas turbines, and high-performance engineering applications due to its exceptional strength and heat resistance. It is commonly found in components like turbine blades, combustion chambers, and exhaust systems, where it withstands extreme temperatures and stresses. The alloy’s excellent corrosion resistance makes it ideal for use in harsh environments, including power generation and petrochemical industries. Additionally, Rene 41 is used in military and defense sectors for parts requiring high-temperature stability, durability, and resistance to oxidation over extended periods.
