Yunus Sheets and Plates, a reputable manufacturer and supplier located in Istanbul, Turkey, is dedicated to providing top-notch Hastelloy B2 Sheets and Plates tailored to meet a variety of industrial needs. With a strong focus on precision engineering and adherence to international standards, the company delivers durable and corrosion-resistant solutions that thrive in harsh chemical environments. Their Hastelloy B2 products are well-known for their exceptional performance, reliability, and longevity. Supported by state-of-the-art manufacturing facilities, thorough quality checks, and a customer-centric approach, Yunus Sheets and Plates guarantees excellence in every product, serving industries around the globe with trustworthy materials that boost operational efficiency.
Hastelloy B2 Sheets and Plates are primarily made up of nickel and molybdenum, along with small amounts of iron, cobalt, and other elements that enhance stability and mechanical strength. This unique composition provides remarkable resistance to hydrochloric acid, hydrogen chloride gas, and other aggressive reducing agents. The sheets and plates exhibit high tensile strength, good ductility, and impressive toughness, even at elevated temperatures. Their carefully controlled carbon and silicon levels help reduce carbide precipitation during welding, making them easier to work with. These mechanical properties position Hastelloy B2 as a dependable material for challenging environments where both strength and corrosion resistance are crucial.
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grade | ASME SB333, ASTM B333 UNS N10665, ASTM B333 UNS N010675, AMS, MSRR, BS |
| Length | 0-12mm or as required |
| Specification of ASTM B333 Alloy B2 Plate | ASTM B333 UNS N10665, ASME SB333, MSRR, BS, AMS 4544 sheet |
| Alloy B2 Plate Width | 0-2500mm or as required |
| UNS N10665 Plate Thickness | 0.3 to 1200 mm or as required |
| Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B333 Alloy B2 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Alloy B2 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Balance | 0.02 max | 26 – 30 | 1.00 max | 0.1 max | 2.0 max | 0.04 max | 0.03 max | 1.0 max | 1.0 max |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Alloy B2 | 9.2 g/cm3 | 1370 °C (2500 °F) | Psi – 51000 , MPa – 350 | Psi – 1,10,000 , MPa – 760 | 40 % |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Alloy B2 | N10665 | 2.4617 | – | – | – | – | – |
|
Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.125″ |
3.18mm |
|
.134″ |
3.40mm |
|
.156″ |
3.96mm |
|
.187″ |
4.75mm |
|
.250″ |
6.35mm |
|
.312″ |
7.92mm |
|
.375″ |
9.53mm |
|
.500″ |
12.7mm |
|
.600″ |
15.9mm |
|
.750″ |
19.1mm |
|
.875″ |
22.2mm |
|
1″ |
25.4mm |
|
1.125″ |
28.6mm |
|
1.250″ |
31.8mm |
|
1.500″ |
38.1mm |
|
1.750″ |
44.5mm |
|
2″ |
50.8mm |
|
2.500″ |
63.5mm |
|
3″ |
76.2mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Hastelloy B2 sheets and plates offer exceptional advantages particularly in highly corrosive environments. Known for their superior resistance to hydrochloric acid, sulfuric acid, and other aggressive chemicals, they are ideal for chemical processing, storage, and handling systems. Their high strength and excellent resistance to pitting, crevice corrosion, and stress corrosion cracking ensure long-lasting performance. Additionally, Hastelloy B2 provides outstanding weldability and formability making it easy to fabricate for complex applications. Its ability to maintain structural integrity under extreme conditions reduces maintenance and downtime, enhancing operational efficiency in industries such as pharmaceuticals, chemical and petrochemical.
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
Hastelloy B2 Sheets and Plates find extensive use in industries that demand exceptional resistance to highly corrosive conditions. They are commonly utilized in chemical processing equipment, reactors, heat exchangers, and evaporators that handle strong reducing agents. Their ability to endure hydrochloric acid makes them particularly suitable for petrochemical industries, acid production facilities, and pharmaceutical equipment. Furthermore, they are used in pollution control, marine applications, and components that are exposed to contaminated reducing environments. With their outstanding durability, these materials are a go-to choice for many demanding applications.
