Yunus Sheets and Plates, based in Istanbul, Turkey, has built a solid reputation as a leading manufacturer and supplier of high-performance **Grade Mar M247 Sheets and Plates**. These sheets and plates are celebrated for their remarkable heat resistance, strength, and durability, making them perfect for extreme service conditions. The company adheres to rigorous quality standards to ensure that every product consistently performs well in critical applications. Catering to industries like aerospace, power generation, petrochemical, and marine, Yunus Sheets and Plates delivers reliable solutions designed for demanding environments, establishing itself as a trusted name for advanced alloy sheet and plate needs around the globe.
**Grade Mar M247 Sheets and Plates** are nickel-based superalloys that stand out for their exceptional mechanical strength and thermal stability. Their unique composition, which includes nickel, cobalt, chromium, aluminum, titanium, tungsten, and tantalum, grants them excellent resistance to oxidation and creep at high temperatures. With impressive tensile strength and outstanding fatigue resistance, these sheets and plates maintain their structural integrity even when faced with extreme thermal cycling. Mar M247 is known for its excellent microstructural stability and durability, making it the go-to choice for high-stress, high-temperature applications where long-term performance and reliability are a must.
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Cr | Co | Mo | W | Al | Ti | Ta | Hf | B | C | Zr | Ni |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MAR M247 | 8.0 | 10.0 | 0.7 | 10.0 | 6.0 | 1.0 | 3.0 | 1.0 | 0.015 | 0.15 | 0.05 | Bal |
| Yield Rp0.2 (MPa) | Tensile Rm (MPa) | Impact KV (J) | Elongation A (%) | Reduction in cross section on fracture Z (%) | As-Heat-Treated Condition | HBW |
|---|---|---|---|---|---|---|
| 221 (≥) | 571 (≥) | 32 | 32 | 42 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 221 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Grade Mar M247 is a high-performance nickel-based superalloy known for its excellent machinability at elevated temperatures. Provides exceptional strength, oxidation resistance, and thermal stability, making it ideal for turbine blades, rotors, and other highly stressful aerospace and industrial applications Highly resistant to creep, fatigue, and corrosion ho makes reflections last longer and last longer into harsh environments. Mar M247 sheets and plates provide excellent weldability and formability, resulting in stable shapes and patterns. This alloy is essential for advanced industrial applications requiring high temperature and pressure resistance.
You’ll find **Grade Mar M247 Sheets and Plates** widely used in industries that demand materials capable of withstanding intense heat and pressure. They are commonly found in **aerospace turbine blades, jet engine components, power generation turbines, and gas turbine hot sections**, thanks to their ability to endure high temperatures. Additionally, they play a vital role in **petrochemical processing, marine engines, and high-performance automotive applications**, where strength and thermal resistance are essential. Their superior oxidation resistance, creep strength, and fatigue performance make them the preferred option for **critical rotating parts, combustion systems, and structural components**.
