Yunus Sheets and Plates, located in Istanbul, Turkey, stands out as a top-notch manufacturer and supplier of high-quality Duplex Steel Sheets and Plates. They cater to industries around the globe, providing reliable steel solutions that don’t compromise on quality. Known for their precision engineering and strict compliance with international standards, the company delivers durable and cost-effective products tailored to meet a variety of industrial needs. Their Duplex Steel Sheets and Plates are designed to offer impressive strength and exceptional corrosion resistance, making them perfect for even the toughest environments. With a strong focus on customer satisfaction, Yunus Sheets and Plates has earned a reputation as a trusted partner for industries in search of long-lasting and efficient material solutions.
These Duplex Steel Sheets and Plates feature a balanced mix of austenitic and ferritic microstructures, incorporating elements like chromium (about 22%), nickel (4–6%), molybdenum (3%), and nitrogen. This unique composition significantly boosts their resistance to stress corrosion cracking, pitting, and crevice corrosion. On the mechanical side, they boast high tensile strength, superior yield strength, and excellent toughness, outshining conventional stainless steels. Their low thermal expansion, good weldability, and outstanding fatigue strength make them a reliable choice for critical applications across various industries that demand durability and corrosion resistance.
| Specifications | ASTM A240 / ASME SA 240 |
| Duplex Steel Plate Grades | 2205, 2507 |
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Width | 10-2500mm |
| Length | 2m,2.44m, 3m as per requirement |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| MN | C | SI | S | P | CR | NI | MO | N |
|---|---|---|---|---|---|---|---|---|
| 2.0 max | 0.03 max | 1.0 max | 0.02 max | 0.03 max | min: 21.0 max: 23.0 | min: 4.5 max: 6.5 | min: 2.5 max: 3.5 | min: 0.08 max: 0.20 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Duplex Steel Sheets and Plates offer numerous advantages, including superior strength, high resistance to corrosion, and exceptional durability in aggressive environments. The combination of austenitic and ferritic microstructures provides enhanced resistance to stress corrosion cracking, pitting, and crevice corrosion. They are known for their high tensile strength, which makes them ideal for high-pressure and high-temperature applications. Additionally, Duplex Steel offers excellent weldability and formability, making it suitable for a wide range of industries, including oil and gas, chemical, marine, and structural applications. Its cost-effectiveness further adds to its appeal.
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
Duplex Steel Sheets and Plates find their place in industries where strength and corrosion resistance are paramount. They are widely used in chemical processing plants, desalination facilities, and marine environments, thanks to their exceptional resistance to chloride-induced corrosion. In the oil and gas sector, they are perfect for offshore platforms, pipelines, and pressure vessels. Power generation plants utilize them in heat exchangers, boilers, and condensers. Additionally, they are employed in the paper and pulp industries, construction, and architectural structures, ensuring a long service life and dependable performance even in harsh and demanding operating conditions.
