Yunus Sheets and Plates, located in Istanbul, Turkey, stands out as a top-notch manufacturer and supplier of premium Brass Sheets and Plates. Known for their unwavering dedication to precision and quality, this company caters to a wide range of industrial and commercial sectors, providing products that adhere to strict international standards. With cutting-edge manufacturing facilities and a passionate team of experts, Yunus Sheets and Plates guarantees consistent quality, durability, and visual appeal in every brass item they produce. Their Brass Sheets and Plates are celebrated for their exceptional finish, corrosion resistance, and reliability, making them a go-to choice for clients around the globe.
Brass Sheets and Plates are mainly made up of copper and zinc, with the proportions varying based on the desired characteristics. This alloy is known for its impressive corrosion resistance, high thermal and electrical conductivity, and good machinability. In terms of mechanical properties, it boasts moderate tensile strength, notable hardness, and significant ductility, which makes it ideal for forming and bending tasks. Moreover, brass has low friction properties and good wear resistance, ensuring it performs well in mechanical components and decorative applications. The blend of these qualities makes brass a versatile option for both functional and aesthetic purposes.
| Standard | ASTM, AISI, EN, BS, JIS, ISO, GB | ||
|---|---|---|---|
| Grade | H59, H62, H65, H68, H70, H80, H85, H90, H96 | ||
| Size | Thickness: 0.1-500mm Width: 1mm-5000mm Length: 1m, 2m, 3mor as required | ||
| Surface | mill, polished, bright, oiled, hair line, brush, mirror, sand blast, Manufacturer and Supplier | ||
| Application | Brass plate has a high corrosion resistance, and have good plasticity, in the air easy to cold and hot pressure processing, easy to welding, forging and tin, no stress corrosion cracking the tendency. | ||
| Package | Standard export seaworthy package, suit for all kinds of transport, or as required. | ||
| Constituent | Alloys Designation precent | |
|---|---|---|
| CuZn30 | CuZn37 | |
| Copper | 68.5 to 71.0 | 62.0 to 65.0 |
| Lead, max | 0.05 | 0.30 |
| Iron, max | 0.5 | 0.10 |
| Total impurities, max | 0.03 | 0.60 |
| Zink | Reminder | Reminder |
| Property | Sheet |
|---|---|
| Tensile Strength | 300 – 550 MPa |
| Proof Stress | 110 – 500 MPa |
| Elongation A50 mm | 38 – 3% |
| Hardness Vickers | 55 – 180 HV |
| Hardness Brinell | – |
| Property | Value |
| Density | 8.44 kg/m3 |
| Melting Point | 916°C |
| Modulus of Elasticity | 103.4 GPa |
| Thermal Conductivity | 116 W/m.K |
| Thermal Expansion | 20.5×10-6 /°C |
| Thickness (mm) | Tolerance in mm Plus or Minus (+ or -) |
|---|---|
| Over 0.3 to 0.4 | 0.07 |
| Over 0.4 to 0.5 | 0.08 |
| Over 0.5 to 0.8 | 0.09 |
| Over 0.8 to 1.2 | 0.10 |
| Over 1.2 to 1.8 | 0.11 |
| Over 1.8 to 2.5 | 0.13 |
| Over 2.5 to 3.2 | 0.17 |
| Over 3.2 to 4.0 | 0.20 |
| Over 4.0 to 5.0 | 0.23 |
| Over 5.0 to 6.0 | 0.26 |
| Over 6.0 to 7.0 | 0.29 |
| Over 7.0 to 8.0 | 0.32 |
| Over 8.0 to 9.0 | 0.35 |
| Over 9.0 to 10.0 | 0.38 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Brass sheets and plates provide splendid blessings, together with excessive corrosion resistance, making them best for marine and business packages. Their extraordinary machinability and ductility ensure ease of fabrication into problematic designs. Brass exhibits advanced thermal and electrical conductivity, improving overall performance in warmness exchangers and electrical additives. Its appealing gold-like appearance provides aesthetic value, suitable for ornamental purposes. Additionally, brass is durable, recyclable, and resistant to tarnishing, making sure long-term fee-effectiveness. Versatility across industries, from creation to automobile, highlights the value of brass sheets and plates in numerous environments.
Brass Sheets and Plates are utilized across various industries thanks to their strength, durability, and appealing look. They are commonly found in architectural and decorative features, such as panels, facades, and trim. In the realm of mechanical engineering, brass is used to create gears, valves, and bearings due to its low friction and wear resistance. The electrical and electronics sector relies on brass for connectors, terminals, and circuit components because of its excellent conductivity. Additionally, brass is favored for musical instruments, plumbing fittings, and precision instruments. Its combination of workability and visual charm makes it essential in both industrial and decorative applications.
